Finaly another update that is actually based on the course. I have finished creating my lighting scene which I believe came out amazing. I had taken the model that our course instructor had made and textured it and lit it. Here are some pictures that follow the texturing to the final product.
Monday 15 November 2010
Monday 15th of November, My Biggest Post Ever!!!
Thought I would do a quick update on my post, as I thought it would be interesting to show the equipment I am using for the course and explain some of the parts and give help to those interested in a new machine. Remember this is a brief tutorial please do further research on components.
This PC system was built with 3D design and rendering in mind. It is based around an AMD Phenom II X6 (~£169) six-core processor. Now with games you want less cores with more power (this is because at the moment games can only utilize four cores), but with rendering you want more cores with any power you get for example mine are currently running at 2.8 GHz, I hope to overclock this to 3.5 GHz in order to squeeze out more performance. On top of this I have placed a third party heat sink and cooler, this disperses the heat away from the chip giving it a longer life (I would highly recommend this as when rendering the machine will be running at 100% for a long time and thus generate a large amount of heat).
On to the RAM, now again with this the more the better, where games can only utilize 4 GB of RAM your design program has access to all of the memory, at the moment the sweet spot seems to be 8GB. I went for some Patriot Sector 5 DDR3 memory in an 8GB kit (~£65 each kit of 4GB). However if you own or plan on buying one of the new i7 cores you can utilize triple channel memory which allows you to install up to six RAM sticks. With any other you are currently limited to four. A named brand is good to go for here as they are reliable and usually come with built in heat dispersers (A note with these, make sure that the third party heat sink and fan will fit if you have filled the RAM slots with sticks with heat dispersers).
The graphics card will do a lot of grunt work while you are editing and creating your 3D models, and not a lot while rendering that's the job of the CPU and RAM. I selected an AMD HD 6870 (~£240) for my card as it had achieved good benchmarks with rendering live 3D and is the newest of the AMD line-up. Now when choosing a card you have to look at all the different models out there. I'll save you the work and give you a few of the best ones out there. The ATI HD 5850 1GB (~£215) won last years graphics card of the year. 'Nuff said, and it won't break the wallet (trust me cards can get very expensive). The new generation AMD card to pick is the HD 6870 1GB it runs faster than the 5850 and comes stereoscopic 3D ready. Now on the NVDIA side of things is the 460 GTX 1GB (~£160) and that's it really until the new line up is released. Their 470 and 480 cards run too expensive and too hot. Expect to pay anything between £160 to £260 for a decent card, some even come factory overclocked. Most new motherboards come with a feature called SLI (NVIDIA) or Cross-Fire (AMD) which allows you to run two graphics cards allowing for future expansion of the system.
Now this is the bit most people skimp on, but a good power supply will last longer and provide your components with the right amount of power. Preferably it is best to buy a modular supply, that is one that allows you to choose what cables to run from it, thus helping with cable management.I picked up a Xigmatek NRP 700 watt power supply, named brands are always best yet again for reliability. Also look at the wattage a power supply between 700 and 1000 watts is a good choice to go for as newer graphics cards require power direct form the PSU. It also gives you enough power to run SLI or Cross-Fire.
When choosing a mother board choose one that works with your selected chip. My choice was a Gigabyte 870A-UD3 (~£85) board, now the two best brands to go on here are either Gigabyte or Asus, there is also MSI however I've heard of some issues with their boards. The preferred size of board would be an ATX board I would only recommend a micro-ATX board I you have case restrictions, but if you are building from scratch you shouldn't have any. I you wish you expand to two graphics cards ensure that they are SLI or Cross-Fire ready. Yet again ensure they are compatible with your chip you can always ask at the store on online.
This is the generic parts of the computer. I have a 1TB (~£60) hard drive and since the price of 1TB drives have gone down this is the best choice as it offers massive amounts of space for less money. In my computer I have included a Blu-ray drive this is not recommended for most people and I have chosen this for watching films. A standard DVD-RW drive will do and these are cheap at around £19. I don't have to tell you about the keyboard and mouse as you obviously know how to use these if you got here. The screen is also entirely up to your own personal choice.
The last part of the build is the case, I have chosen a medium size case as case sizes go in the form of the HAF 922 (~£90) from Coolermaster is a big thing make sure everything is tidy not only does this look nicer but also allows better airflow through the case.
Before and after cable management.
So there you have it a quick tip on a 3D design PC. If you have any questions or queries I and available at gaucho2mark@yahoo.co.uk, I am also available for PC builds. There is also a store on Holburn Street called Everest Tech they sell components and build systems, they will also answer any queries you have (by the way if you purchase all the components to a PC to build yourself you can ask for discounts as they are a small store). Thanks for reading and until the next time.
